Vacuum Gripper Robot, 24V

pre-assembled training model



Product Description

Safe and precise transport of workpieces

Pre-built, 3-axis robot with vacuum gripper works quickly and precisely, positioning workpieces in three-dimensional space.

Working range: x-axis 270°, y-axis (forwards/back) 140 mm, z-axis (up/down) 120 mm.

  • CAUTION: absolutely necessary for operation is a PLC control 24V, not inlcuded


2-minute overview


  • Ideal training, simulation and demonstration model for training and industrial automation
  • Pre-built, stable training model
  • Mounted on a solid wooden plate, model packaged in a sturdy cardboard box
  • Optionally available in the 9V standard voltage as well as in the worldwide 24V industrial standard


  • Model packed in a robust box.
  • Size:  440x200x330mm.
  • Weight (g):  3100 for 9V, 2800 for 24V
  • 3x Encoder motor (DC motor with magnetic encoder)
  • 3x Push button (limit switch)
  • Vacuum exhauster
  • Compressor
  • Solenoid valve






Training models in 9V and 24V

Ready-to-assemble, compact training models for simulating real applications - fischertechnik is also highly regarded by engineers and trainers.

The training and demonstration models from fischertechnik are suitable for education, training and industry. Whether it's at the 9V standard voltage or in the worldwide 24V industry standard, fischertechnik supplies a wide range of simulation models tailored to the needs of your choice.

The training models from fischertechnik are the frequently preferred and proven means to plan, program, develop and test industrial controls with the corresponding software in a realistic and cost-effective manner before large investments are made. They are used worldwide in the areas of education, development, simulation and presentation.



For our training models, we provide CAD data on request - these can be further processed up to the digital twin.

The 3D animation shown here was created by Accelerated Solutions GmbH and is for demonstration purposes.

Connections of the flexible and modular fischertechnik system with industry-compatible actuators and sensors as well as controls of leading manufacturers open up almost unlimited possibilities for hardware simulation.

Complicated, technical systems are presented realistically and so perfectly simulated that they are comprehensible to everyone. Large industrial projects can be depicted in the model. This makes the functionality and feasibility clear.


The connections of the flexible and modular fischertechnik system with industrial actuators and sensors as well as the control systems of leading manufacturers open up almost unlimited possibilities for hardware simulation.

The fischertechnik simulation and training models thus open up flexible possibilities for industry, education and schools to test processes and to communicate technical basics easily.


Light metal foundry of the BMW Group

In the light metal foundry of the BMW Group's Landshut plant, the start-up of the production facilities is to be made safer and more efficient with the help of two measures: Standardization and virtual commissioning.

>> To the project


SmARt Factory - fischertechnik factory model virtually extended

As part of a project, the company Accso GmbH enables the planning, analysis and visualization of production plants with the SmARt Factory and augmented reality applications.

>> To the project


From a 3D CAD model of the high-bay warehouse a digital twin was created - Furtwangen University

With the digital twin, it was shown how the development of a control program can be carried out via SiL (Software in the Loop) simulation without physically existing hardware, thus enabling virtual commissioning of the complete plant.

>> To the project


IoT simulation - Objektkultur Software GmbH

With the help of IoT simulation, Objektkultur Software GmbH was able to show how a factory equipped with IoT can be quickly and securely integrated into the existing IT and controlled in the cloud.

>> To the project


Pilz Education Systems PES - Pilz GmbH & Co. KG

The Pilz Education Systems PES are modular training systems with modern industrially used components for practical instruction in electrical engineering.

>> To the project


RISE Remote Support - RISE Technologies GmbH

RISE Technologies GmbH is a software service provider and regularly travels to major trade fairs to demonstrate its digital innovation RISE Remote Support and make it tangible for visitors.

>> To the project


Sorting line with colour recognition - Staatliche Technikakademie Weilburg

The students of the Staatliche Technikakademie Weilburg programmed an independent project with fischertechnik using LabView. They extended the part of the sorting line with colour recognition from the factory simulation and turned it into an independent project.

>>To the project


Programming a fischertechnik model - Staatliche Technikakademie Weilburg

The students of the Staatliche Technikakademie Weilburg programmed an independent project with fischertechnik using LabView. They removed the sorting line and the cycle line from the factory simulation and installed these two components together.

>> To the project

HK$ 8,167.00
